How to reset your Entry Sensor

Resetting is needed if you:

• want to connect your entry sensor to another hub
• need to perform a factory reset to eliminate abnormal behavior.

The reset button is marked with a small ring on the front of the sensor.

Steps for resetting

1. Locate the reset button, marked with a small ring on the front of the sensor.
2. Press and hold down the reset button for approximately 14-16 seconds.
3. While you are holding the button down, the LED first flashes once, then two times in a row, and finally numerous times in a row.

4. Release the button while the LED is flashing numerous times in a row.
5. After you release the button, the LED shows one long flash, and the reset is completed.
6. A power-cycle of the sensor is needed before you re-pair it to the hub.
